Key Features
Easily Integrated
Integrates easily with Centrias window, louver and
sunshade systems to provide a complete envelope
system.Single Component
Provides all necessary building control layers along with
an outstanding aesthetic.Pressure-equalized
Panels feature a pressure-equalized side joint to
help prevent water infiltration.Panel Profiles
To produce unique and exciting projects, establish a distinctive, coherent design pattern with diverse shapes and sizes.
Specifications
FWDS
PANEL THICKNESS 2" [51mm]
2.5" [64mm]
3"-T [76mm]THERMAL VALUESE R-16 (U=0.069)
R-20.1 (U=0.056)
R-24.1 (U=0.045)PANEL WIDTHS Standard Modules:
24" [610mm]
30" [762mm]
36" [914mm]
Custom Modules:
10"- 40" [254-1016mm]PANEL LENGTHS Smooth - 16' [4.9m] max.
Smooth Striated - 20' [6.1m] max.
Embossed Striated - 37' [11.3m] max.
Embossed - 37' [11.3m] max.
304 Stainless - 16' [4.9m] max.GRPAHIC SERIES
PANEL THICKNESS 2.5" [64mm]
3"-T [76mm]THERMAL VALUESE R-20.1 (U=0.056)
R-24.1 (U=0.045)PANEL WIDTHS 10"- 40" [254-1016mm] PANEL LENGTHS Smooth - 16' [4.9m] max.
Smooth Striated - 20' [6.1m] max.
Embossed Striated - 20' [6.1m] max.
Embossed - 20' [6.1m] max.DS58
PANEL THICKNESS 2" [51mm]
2.5" [64mm]
3"-T [76mm]THERMAL VALUESE R-14 (U=0.072
R-17 (U=0.060)
R-22 (U=0.046)PANEL WIDTHS Standard Modules:
24" [610mm]
30" [762mm]
36" [914mm]
Custom Modules:
12"– 40" [304–1016mm]PANEL LENGTHS Smooth - 16' [4.9m] max.
Smooth Striated - 20' [6.1m] max.
Embossed Striated - 37' [11.3m] max.
Embossed - 37' [11.3m] max.
304 Stainless - 16' [4.9m] max.Ready to Design Something Amazing?
You know those aha! moments? We're here to help you get there! Schedule an AIA CEU to stay up to date with your credits or request important detail and documents to get started with these amazing products. Don't let anything stand between you and that aha! moment! We can't wait to get you there!
